Barrier Assurance
FEATURES
The Bow Tie Module incorporates existing hazard analysis data to facilitate Risk Analysis and Risk Assessments on mitigative and preventive barriers. Bow Tie analysis is becoming increasingly common at communicating important risk mitigation measures for a wide range of facilities. Integration with the evergreen data in the LOPA Module ensures analysis is using the most up-to-date risk information. Bow Ties provide a visual and interactive experience; allowing users to identify preventive and mitigating barriers. With the barrier assurance workflow, users have a complete picture of all barrier levels to determine the total risk of a hazardous event within the plant.
- Automatically create Bow Ties using existing LOPA data
- Data linkage to other modules
- Bow Tie analysis assessment checklist
- Intuitive graphical interface
- Add unlimited threats, mitigations, and consequences to the top hazard event
- Export via PDF or Excel
- Barrier Assurance checklists and workflows
Data & Reports
SLM V2 BOWTIE BARRIER ASSURANCE DATA OUTPUTS AND REPORTS
The following Data and Reports are part of the SLM V2 core BowTie Barrier Assurance Module.
Managed BowTie Barrier Assurance Data:
- Hazard
- Causes
- Preventative Barriers
- Barrier Assurance Checklists for Preventative Barriers
- Consequences (Type, Effectiveness, Criticality)
- Mitigation Barriers (Type Effectiveness, Criticality)
- Barrier Assurance Checklist's for Mitigation Barriers
- Bow Tie Task Lists
BowTie Barrier Assurance Reports:
- Bow Ties
- Bow Ties Fit For Service Results
Click to zoom image
